This CH-3000 semi-automatic band saw machine is an equipment for cutting metal materials with bi-metal band saw blades, featuring compact construction, fast cutting speed, high precision, narrow kerf, less noise, easy operation etc.. It is an energy-saving product to replace reciprocating sawing machine and is widely used for cutting metal materials in various industries such as construction, automobile, transportation, bridge-building, ship-building etc.
✔ Gantry Type
✔ Semi-automatic
✔ Hydraulic Downfeed
✔ Heavy Duty
MODEL | CH-3000 | |||
Cutting Capacity | 0° | ● | Ø3000 mm | Ø118 1/10" |
0° | ▅ | 3000 mm Wx3000 mm H | 118 1/10" Wx118 1/10" H | |
Drive Capacity | Main Motor | 37 kW | ||
Hydraulic Motor | 11+1.5 kW | |||
Coolant Pump | 0.37 kW | |||
Blade Speed | 12~55 m/min by Inverter | 39~180 fpm by Inverter | ||
Blade Size | 80x1.6x22100 mm | |||
Workpiece Clamping | Hydraulic Vise | |||
Blade Tensioning | Hydraulic | |||
Main Drive | Gear Reducer | |||
Table Height | 1420 mm | |||
Machine Size (LxWxH) | 9470x2550x8475 mm | 372"x100"x334" |
This CH-3000 Gantry type semi-automatic band saw features a gantry type dual-column design and a built in coolant system. In keeping with an exceptionally high standard of machine quality, this Gantry type band saw incorporates infinitely variable band speed for optimum cutting results.it is Heavy-duty production band saw models for solid forgings, slabs, profiles, molds or bundled material.
Accepts a standard 80x1.6x22100 mm blade.
Features
1. Blade Cleaning Brush
2. LED Work Light
3. Saw Frame Height Selector Gauge
4. 2m Power Material Roller Table
5. Hydraulic Blade Tension
6. Laser Projector
7. Inverter
8. Security Switch
9. One Piece of Bi-metal Saw Blade
10. One Set of Tools with Tool Box
11. Instruction Manual
1. Variable Vise Pressure
2. Automatic Chip Conveyor
3. 2m Material Roller Table
4. Hydraulic Shuttle Table Feeding (Standard with 2m Material Roller Table)
